Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

178 Upgrade and Maintenance Manual TX1320 M1
Expansion cards and backup units
9.2.2 Removing expansion cards
9.2.2.1 Preliminary steps
Before removing an expansion card, perform the following steps:
Ê Locate the defective server as described in section "Locating the defective
server" on page 44.
Ê Disable BitLocker functionality as described in section "Disabling BitLocker
functionality" on page 73.
Ê Disable boot watchdog functionality as described in section "Disabling
SVOM boot watchdog functionality" on page 74.
Ê Shut down the server as described in section "Shutting down the server" on
page 52.
Ê Disconnect the AC power cord from the system.
Ê If applicable, disconnect external cables to the expansion card.
Ê Remove the server cover as described in section "Opening the server" on
page 55.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
