Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

TX1320 M1 Upgrade and Maintenance Manual 339
Appendix
16.4 Minimum startup configuration
If the server does not start up or other problems occur, it may be necessary to
take the system down to its most basic configuration in order to isolate the
defective component.
The minimum startup configuration consists of the following components and
cables:
Ê Shut down the server as described in section "Shutting down the server" on
page 52.
Ê Remove the AC power cord from the cable tie and disconnect it from the
system as described in section "Disconnecting power cords" on page 53.
Ê Take the system down to its minimum startup configuration.
Ê Reconnect the AC power cord to the power supply unit and secure it with a
cable tie as described in section "Connecting the server to the mains" on
page 67.
Field Replaceable Units (FRU)
Component Notes and reference
System board no TPM, UFM or expansion cards installed
CPU with CPU heat sink no fan (disconnect fan cable)
1 memory module
installed in DIMM slot 1A, see section
"Memory sequence" on page 217
Front panel module
Power supply unit
Table 7: Minimum startup configuration - components
Cable Notes and reference
Front panel cable
Power cable
Table 8: Minimum startup configuration - cables

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
