Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

142 Upgrade and Maintenance Manual TX1320 M1
Hard disk drives / solid state drives
7.4.1.2 Removing the air duct (if applicable)
Figure 51: Lifting up the air duct
Ê Lift up the right cant of the air duct.
Figure 52: Removing the air duct
Ê Remove the air duct in direction of the arrow.

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
