Fujitsu PRIMERGY TX1320 M1

TX1320 M1 Upgrade and Maintenance Manual 141
Hard disk drives / solid state drives
Figure 50: Disconnecting the SATA cables from the system board
Ê Disconnect the SATA cable from the system board.
Ê Open the front cage as described in section "Opening the front cage" on
page 60.
Ê Remove the HDD fan as described in section "Removing the HDD fan
module" on page 166.
