192 Upgrade and Maintenance Manual TX1320 M1
Expansion cards and backup units
9.3.2 Removing an FBU
V CAUTION!
Do not throw FBUs into the trash can. Batteries must be disposed of in
accordance with local regulations concerning special waste.
For further safety information, please refer to section "Environmental
protection" in the FUJITSU Server PRIMERGY TX1320 M1 Operating
Manual.
9.3.2.1 Preliminary steps
Before removing an FBU, perform the following steps:
Ê Locate the defective server as described in section "Locating the defective
server" on page 44.
Ê Shut down the defective server as described in section "Shutting down the
server" on page 52.
Ê Disconnect the AC power cord from the system.
Ê Remove the server cover as described in section "Opening the server" on
page 55.
Ê Open the front cage as described in section "Opening the front cage" on
page 60.
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
