Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

234 Upgrade and Maintenance Manual TX1320 M1
Processors
11.3 Replacing the processor heat sink
11.3.1 Preliminary steps
Ê "Locating the defective server" on page 44
Ê "Shutting down the server" on page 52
Ê "Opening the server" on page 55
Ê "Removing the system fan module" on page 153
11.3.2 Replacing the processor heat sink
Ê Remove the processor heat sink as described in section "Removing the
processor heat sink" on page 225.
Ê Apply thermal paste to the processor surface as described in section
"Applying thermal paste" on page 229.
Ê Install the processor heat sink as described in section "Installing the
processor heat sink" on page 231.
11.3.3 Concluding steps
Ê "Installing the system fan module" on page 156
Ê "Closing the server" on page 64
Ê "Connecting the server to the mains" on page 67
Ê "Switching on the server" on page 71
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
