TX1320 M1 Upgrade and Maintenance Manual 283
System board and components
● Do not throw batteries into the trash can. Lithium batteries must be
disposed of in accordance with local regulations concerning special
waste.
● For further safety information, please refer to section "Environmental
protection" in the operating manual of your server.
● Ensure to insert the CMOS battery the with the positive pole
facing up!
14.2.1 Preliminary steps
Ê "Locating the defective server" on page 44
Ê "Shutting down the server" on page 52
Ê "Disconnecting power cords" on page 53
Ê "Opening the server" on page 55
14.2.2 Replacing the defective CMOS battery
Figure 168: Removing the CMOS battery
