TX1320 M1 Upgrade and Maintenance Manual 323
Appendix
16.1.3 Server interior
Figure 203: PRIMERGY TX1320 M1 interior (2.5-inch HDD / standard PSU model)
Pos. Component Reference
1 System fan "Replacing the system fan module" on
page 152
2 Expansion card slots "Replacing expansion cards" on page 181
3 Processor / CPU heat
sink
"Upgrading or replacing the processor" on
page 224
4 TPM board "Replacing the TPM" on page 301
5 CMOS battery "Replacing the CMOS battery" on
page 282
6 UFM board "Replacing the UFM" on page 290
7 SAS / SATA HDD / SSD
backplane
"Replacing SAS / SATA backplane" on
page 140
8FBU "Replacing an FBU" on page 195
9 HDD / SSD drive bay "Hard disk drives / solid state drives" on
page 115
햲
햳
햴
햵
햶
햷
햸
햹
햺
햻
햽
햾
햿
헀

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
