Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

128 Upgrade and Maintenance Manual TX1320 M1
Hard disk drives / solid state drives
7.3 3.5-inch hard disk drives
7.3.1 Mounting order for 3.5-inch HDDs
Maximum configuration: 2x 3.5-inch HDDs
Figure 42: 3.5-inch HDD mounting order
HDD naming scheme
Bay RAID Manager Channel Logical drive number
21 1 1
10 1 0
1
2

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
