Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

28 Upgrade and Maintenance Manual TX1320 M1
Before you start
2.4 Documents you need at hand
Maintenance procedures may include references to additional documentation.
When preparing the maintenance task, ensure that all required manuals are
available according to the overview below.
I – Ensure to store all printed manuals enclosed with your server in a
save place for future reference.
– Unless stated otherwise, all manuals are available online at
http://manuals.ts.fujitsu.com under Industry standard servers or from the
ServerView Suite DVD supplied with your PRIMERGY server.
For the Japanese market please use the following address:
http://jp.fujitsu.com/platform/server/primergy/manual/
Phillips
PH1 / (+) No. 1
TFM module M2.5 x 4 mm
(silver)
C26192-Y10-
C103
Document Description
"Quick Start Hardware -
PRIMERGY Server TX1320 M1"
leaflet
" はじめにお読みください -
PRIMERGY TX1320 M1 " リー
フレット for the Japanese
market
Quick installation poster for initial operation,
available only in printed form
"Safety notes and regulations"
manual
" 安全上のご注意 " for the
Japanese market
Important safety information, available
online or as a printed copy
Table 3: Documentation you need at hand
Screw driver /
Bit insert
Screw Usage Type
Table 2: List of required tools and used screws

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
