Fujitsu PRIMERGY TX1320 M1

TX1320 M1 Upgrade and Maintenance Manual 69
Basic hardware procedures
4.8 Installing the security cover
The PRIMERGY TX1320 M1 can be equipped with an optional security cover.
Figure 25: Rear side of the server
Ê Connect the data cables to the connectors of the external connector
panel (1).
Ê Insert the tabs of the security cover into the holes of the rear side of the
server (2).
/
