44 Upgrade and Maintenance Manual TX1320 M1
Basic hardware procedures
4.1.1 Locating the defective server
Figure 2: Identification button and indicator on front panel
Figure 3: Indicators on the connector panel: CSS, Global Error and ID indicators
When working in a datacenter environment, switch on the ID indicator on the
front and rear connector panels of the server for easy identification.
1 CSS, Global Error and ID indicators (yellow, orange and blue)
1
0
/

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
