4.6.2 Mounting the drive cover
Figure 21: Installing drive cover
Ê Insert the drive cover to the upper side of the side / top cover (1).
Ê Close the drive cover (2).
Ê Turn the key anticlockwise (3).
I Depending on the setting of the green hook in the drive cover, you
must turning the key or not (For further information, please refer to the
Operating Manual section "opening the drive cover").
