180 Upgrade and Maintenance Manual TX1320 M1
Expansion cards and backup units
9.2.2.3 Installing a PCI slot bracket
V CAUTION!
Always replace slot brackets into unused PCI slot openings to comply
with applicable EMC regulations and satisfy cooling requirements.
Figure 83: Installing a PCI slot bracket
Ê Insert a PCI slot bracket into the unused PCI slot opening.
Ê Fold down slot bracket clamp until it locks in place.
9.2.2.4 Concluding steps
Perform the following procedures to complete the task:
Ê Close the server cover as described in section "Closing the server" on
page 64.
Ê Reconnect the AC power cord to the power supply unit.
Ê Enable boot watchdog functionality as described in section "Enabling SVOM
boot watchdog functionality" on page 92.

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
