TX1320 M1 Upgrade and Maintenance Manual 261
Accessible drives
12.3.3 Replacing a backup drive
12.3.3.1 Preliminary steps
Before installing an accessible drive, perform the following steps:
Ê Disable BitLocker functionality as described in section "Disabling BitLocker
functionality" on page 73.
Ê Remove any backup medium from the drive.
Ê Shut down the server as described in section "Shutting down the server" on
page 52.
Ê Disconnect the AC power cord from the system.
Ê Remove the server cover as described in section "Opening the server" on
page 55.
12.3.3.2 Replacing a backup drive
Ê Remove the defective backup drive as described in section "Removing
backup drive" on page 257.
Ê Install the new backup drive as described in section "Installing backup drive"
on page 252.
Field Replaceable Unit
(FRU)
Hardware: 10minutes
Tools:
Preliminary and concluding steps: tool-less
Removing accessible drives: Phillips PH2 / (+) No. 2 screw driver

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
