Fujitsu PRIMERGY TX1320 M1 Upgrade And Maintenance Manual

276 Upgrade and Maintenance Manual TX1320 M1
Front panel
Figure 164: Removing the front panel module
Ê Disconnect the front panel cable from the front panel module (1).
Ê Disengage the retention hooks of the front panel module (2).
Ê Remove the defective front panel module.
Ê Fold down the front cage.
햲
햳
햳

Fujitsu PRIMERGY TX1320 M1 Specifications

General

Processor Sockets	1
Memory Slots	4
Form Factor	Tower
Processor	Intel Celeron
Storage	Up to 4 x 3.5" or 2.5" drives
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
RAID Support	RAID 0, 1, 10
Network Controller	Dual-port Gigabit Ethernet
Operating System Support	Linux
