Fujitsu PRIMERGY TX1320 M1

54 Upgrade and Maintenance Manual TX1320 M1
Basic hardware procedures
Removing security cover
Figure 10: Removing the security cover
Ê Insert the key (1).
Ê While pressing the key on the screw turn the key counter-clockwise and
remove the screw.
Ê Remove the security cover (2).
/
