Batch Process Manager | Batch Process Manager (option 154)
15
616
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
The file name of a job list must always begin with a
letter.
Create a job list in the Batch Process Manager as follows:
Press the Batch Process Manager key
The control opens the Batch Process Manager.
Press the NEW FILE soft key
The control opens the Create Pallet File ... pop-
up window.
Enter the target directory and any desired file
name in the pop-up window
Press the ENT key
The control opens an empty job list.
As an alternative, press Save
Press the INSERT REMOVE soft key
Press the INSERT AFTER soft key
The control displays the various types on the
right-hand side.
Select the desired type
Pallet
Fixture
Program
The control inserts an empty line in the job list.
The control shows the selected type on the
right-hand side.
Define the entries
Name: Enter the name directly or select one
by means of the pop-up window, if there is
one
Datum table: Enter the datum directly, if
required, or select one by means of the pop-
up window
Preset: Enter the workpiece preset directly, if
required
Locked: Lock the selected line
Editing possible: The selected line cannot be
edited
Confirm your entries by pressing the ENT key.
Repeat the steps if required
Press the EDIT soft key
