HEIDENHAIN TNC 620 Programming Station User Manual

Manual Operation and Setup | Tilting the working plane (option 8)
16
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
691
The control uses the following transformation types for
tilting:
COORD ROT
if a PLANE function was previously executed with
COORD ROT
after PLANE RESET
with corresponding configuration of the machine
parameter CfgRotWorkPlane (no. 201200) by the
machine tool builder
after starting the control
after switching the kinematics
after running the cycle 19 WORKING PLANE
TABLE ROT
if a PLANE function was previously executed with
TABLE ROT
with corresponding configuration of the machine
parameter CfgRotWorkPlane (no. 201200) by the
machine tool builder
after starting the control
after switching the kinematics
after running the cycle 19 WORKING PLANE
If tilting was active when the control was turned off,
then the control also moves in the tilted working plane
when it is turned on again.
Further information: "Crossing the reference point in a
tilted working plane", page 623
To deactivate manual tilting
To deactivate, set the appropriate operating modes to Inactive in
the Tilt working plane menu.
Even if the 3D-ROT dialog in the Manual operation mode is set
to Active, resetting the tilting (PLANE RESET) with an active basic
transformation still functions correctly.
