Test Run and Program Run | Test run

714

HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017

Refer to your machine manual.

Your machine tool builder can also define a tool-change

macro for the Test Run operating mode. This macro will

simulate the exact behavior of the machine.

In doing so, the machine tool builder often changes the

simulated tool change position.
