MOD Functions | Select the position display
19
748
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
Display Function
ACTDST Distance remaining to the programmed position
in the input coordinate system; difference
between actual and target positions
Examples with Cycle 11:
Scaling factor 0.2
L IX+10
The ACTDST display shows 10 mm.
The scaling factor does not have any
influence.
Example with Cycle 11 and tilled working plane:
Tilt A by 45°
Scaling factor 0.2
L IX+10
The ACTDST display shows 10 mm.
The scaling factor and the tilt do not have any
influence.
REFDST Distance remaining to the programmed position
in the machine coordinate system; difference
between actual and target positions
Examples with Cycle 11
Scaling factor 0.2
L IX+10
The REFDST display shows 2 mm.
The scaling factor has an effect on the
distance and thus on the display.
Example with Cycle 11 and tilled working plane:
Tilt A by 45°
Scaling factor 0.2
L IX+10
The REFDST display shows 1.4 mm in the X
and Z axes.
The scaling factor and the tilt have an effect
on the distance and thus on the display.
M118 Traverse paths that were executed with
handwheel superimpositioning function (M118)
With the MOD function Position display 1, you can select the
position display in the status display.
With the MOD function Position display 2, you can select the
position display in the additional status display.
