Tables and Overviews | Functions of the TNC 620 and the iTNC 530 compared
20
816
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
M Effect TNC 620 iTNC 530
M112
M113
Enter contour transitions between any two contour transi-
tions
Reset M112
– (recommended:
Cycle 32)
X
M114
M115
Automatic compensation of machine geometry when
working with tilted axes
Reset M114
– (recommended:
M128, TCPM)
X, option 8
M116
M117
Feed rate on rotary tables in mm/min
Reset M116
X, option 8 X, option 8
M118 Superimpose handwheel positioning during program run X, option 21 X
M120 Pre-calculate the radius-compensated contour (LOOK
AHEAD)
X, option 21 X
M124 Contour filter – (possible via user
parameters)
X
M126
M127
Shorter-path traverse of rotary axes
Reset M126
X X
M128
M129
Maintaining the position of the tool tip when positioning tilted
axes (TCPM)
Reset M128
X, option 9 X, option 9
M130 Within the positioning block: Points are referenced to the
untilted coordinate system
X X
M134
M135
Precision stop at non-tangential contour transitions when
positioning with rotary axes
Reset M134
– X
M136
M137
Feed rate F in millimeters per spindle revolution
Reset M136
X X
M138 Selection of tilted axes X X
M140 Retraction from the contour in the tool-axis direction X X
M141 Suppress touch probe monitoring X X
M142 Delete modal program information – X
M143 Delete basic rotation X X
M144
M145
Compensating the machine’s kinematic configuration for
ACTUAL/NOMINAL positions at end of block
Reset M144
X, option 9 X, option 9
M148
M149
Automatically retract tool from the contour at an NC stop
Reset M148
X X
M150 Suppress limit switch message – (possible via FN
17)
X
M197 Rounding the corners X –
M200
-
M204
Laser cutting functions – X
