Tables and Overviews | Functions of the TNC 620 and the iTNC 530 compared
20
HEIDENHAIN | TNC 620 | Conversational Programming User's Manual | 10/2017
833
Function TNC 620 iTNC 530
PLANE function:
TABLEROT/COORDROT
Effect:
The transformation types are
effective on all free rotary axes
The control does not always
position the free rotary axis
with TABLEROT, but depending
on the current position, the
programmed spatial angle and
the machine kinematics
Default with missing selection:
COORD ROT is used
Effect
The transformation types are
only effective with a C rotary
axis
With TABLEROT the control
always positions the rotary axis
Default with missing selection:
COORD ROT is used
Machine is configured for axis
angle
All PLANE functions can be
used
Only PLANE AXIAL is executed
Programming an incremental
spatial angle according to PLANE
AXIAL
Error message is issued Incremental spatial angle is
interpreted as an absolute value
Programming an incremental
axis angle according to PLANE
SPATIAL if the machine is
configured for spatial angles
Error message is issued Incremental axis angle is
interpreted as an absolute value
Programming of PLANE
functions with active Cycle 8
MIRROR IMAGE
Mirroring has no influence on
tilting using AXIAL PLANE and
Cycle 19
Function is available with all
PLANE functions
Axis positioning on machines
with two rotary axes
e.g.
L A+0 B+0 C+0
or
L A+Q120 B+Q121 C+Q122
Only possible after a tilting
function (error message if
without a tilting function)
Parameters that are not
defined are given the status
UNDEFINED; they are not given
the value 0
Possible at any time if spatial
angles are used (machine
parameter setting)
The control assigns the value 0
to parameters that are not
defined
Special functions for cycle
programming:
FN 17 Function available
Values are always output in
metric form
Further details are different
Function available
Values are output in the units of
the active NC program
Details are different
FN 18 Function available
Values are always output in
metric form
Further details are different
Function available
Values are output in the unit of
the active NC program
Details are different
Compensation of tool length in the
position display
The tool length entries L and DL
from the tool table are taken into
account in the position display,
from TOOL CALL block depend-
ing on the machine parameter
progToolCallDL(no. 124501)
The tool length entries L and DL
from the tool table are taken into
account in the position display
