Juniper QFX5110 Series User Manual

Figure 64: DC Power Supply Faceplate for a QFX5110
5
5—1— Protective earthing terminalShunt negative input terminals (+RTN)
6—2— Fault LEDShunt positive input terminals (-48V)
7—3— Output LEDTerminal block
8—4— Input LEDEjector lever
CAUTION: The V+ terminals are shunted internally together, as are the V- terminals.
The same polarity terminal can be wired together from the same source to provide
an additional current path in a higher power chassis. Do not connect the terminals
to different sources.
274

Juniper QFX5110 Series Specifications

General

Rack Units	1U
Operating System	Junos OS
Form Factor	Fixed
Management	CLI, SNMP, NETCONF
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Humidity	5% to 90% non-condensing
AC Power Input	100-240 VAC
Power Supply	Redundant, hot-swappable
