Table 103: Details of a Virtual Chassis Member Switch
ExampleDetails
EX3300Model number of the member switch
ID 2
NOTE: If the member switch is not provisioned, the serial
number of the switch is displayed instead of its ID.
Assigned ID that applies to the entire Virtual Chassis
configuration
Master
Possible roles are: Master, Backup, or Linecard
Role of the member switch
Prsnt
Possible statuses are: Prsnt, NotPrsnt, Inactive, or Unprvsnd
Status of the member switch
The status of the member switch is displayed on the image of the switch. If the member switch appears
dimmed, it means the switch is not present, is inactive, or is not provisioned in the Virtual Chassis. If the
member switch does not appear dimmed, it means the switch is present and is active.
Table 104 on page 539 describes the possible status of a member switch.
Table 104: Status of a Member Switch in a Virtual Chassis
It means the member switchIt appears asIf the member switch is
Has established physical and logical connections with
Virtual Chassis member switches.
PrsntPresent
Has been disconnected from the existing Virtual Chassis.dimmed and
NotPrsnt
Not present
Has established physical connections, but is unable to
establish logical connections.
dimmed and
Inactive
Inactive
Cannot synchronize with the existing preprovisioned Virtual
Chassis.
dimmed and
Unprvsnd
Not provisioned
Click Rear View for a graphical view of the rear panel of the switch.
