Table 111: Chassis Viewer for EX4300 Switches
DescriptionField
Front View
In the image, the colors listed below denote the interface status for both copper and fiber
media type of ports:
•
Green—Interface is up and operational.
•
Yellow—Interface is up but is nonoperational.
•
Gray—Interface is down and nonoperational.
Mouse over the interface (port) to view more information.
Interface status
LCD panel configured for the LEDs on the ports. Mouse over the icon to view the current
character display.
LCD panel
The mini console port is used to connect the switch to the management console.Mini USB console
You can install an uplink module in the PIC 2 slot. Mouse over the ports in the module to
view the details of the ports in module.
24-port and 48-port EX4300 switches support the 4-port 10-Gigabit SFP+ uplink module.
EX4300-32F switches support the 2-port 40-Gigabit QSFP+ uplink module and the 8-port
10-Gigabit SFP+ uplink module.
When you install a transceiver in the port, the following colors denote the interface status:
•
Green—Interface is up and operational.
•
Yellow—Interface is up but is not operational.
•
Gray—Interface is down and not operational.
PIC 2 slot
NOTE: In EX4300 switches the LEDs are seen in the front panel, these are not active.
Rear View of the EX4300 Switch
The management port is used to connect the switch to a management device for out-of-band
management.
Management port
The Console port (RJ-45) is used to connect the switch to a management console or to a
console server.
Console port
Indicates the USB port for the switch.
NOTE: We recommend that you use USB flash drives purchased from Juniper Networks
for your EX Series switch.
USB port
552
