Table 124: Status LED on QSFP+ Ports and QSFP+ Uplink Module Ports
State and DescriptionLCD IndicatorLED
Indicates the status. The status indicators are:
•
Unlit—40-Gigabit port is down.
•
Steadily green—40-Gigabit port is up.
GreenStatus
Table 125 on page 572 describes the Status LED on 100/1000/2500/5000/10000BASE-T Ethernet network
ports on EX4300-48MP and EX4300-48MP-S switches. Use the Factory Reset/Mode button on the far
right side of the front panel to toggle the Status LED to show the different port parameters for the network
ports. You can tell which port parameter is indicated by the Status LED by looking at which port status
mode LED (SPD, DX, EN, and PoE) is lit.
Table 125: Status LED on 100/1000/2500/5000/10000BASE-T Ethernet Network Ports on EX4300-48MP
and EX4300-48MP-S Switches
State and Description
Status Mode
LEDLED
Indicates the administrative status (enabled or disabled). The status indicators are:
•
Green—Port is administratively enabled.
•
Unlit—Port is administratively disabled.
ENStatus
Indicates the duplex mode. The status indicators are:
•
Green—Port is set to full-duplex mode.
•
Unlit—Port is set to half-duplex mode.
NOTE: In EX4300 switches, the ports operate in full-duplex mode only.
DX
Indicates the speed. The speed indicators are:
•
Unlit—10 Mbps
•
Blinking green—100 Mbps
•
Steadily green—1000 Mbps
•
Blinking amber—5000 Mbps
•
Steadily blue—10000 Mbps
SPD
Indicates the PoE mode. The status indicators are:
•
Steadily green—PoE is enabled on the port and a device is drawing power.
•
Blinking green—PoE is enabled on the port, but no power is drawn from the port.
•
Unlit—PoE is not enabled on the port.
POE
572
