host1(config)#snmp-server enable traps bgp trapFilters notice
3. Configure the per-category severity level as debug for the SONET trap
category. This setting overrides the notice trap severity level that was
applicable for the SONET trap category.
host1(config)#snmp-server enable traps sonet per-category-trapFilters debug
The global severity level is configured as notice for all enabled trap categories
except SONET, whose severity level is set as debug. This configuration occurs
because the global severity level is overwritten to the last configured value and
the per-category severity level takes precedence over the global severity level.
■ There is no no version.
■ See snmp-server enable traps.
snmp-server host
■ Use to configure an SNMP trap host to refine the type and severity to traps that
the host receives.
■ A trap destination is the IP address of a client (network management station)
that receives the SNMP traps.
■ You can configure up to eight trap hosts on each virtual router.
■ You can enable the traps listed in “Trap Categories” on page 168.
■ You can filter traps according to the trap severity levels described in Table 22
on page 169.
■ Example
host1(config)# snmp-server host 126.197.10.5 version 2c westford udp-port
162 snmp link trapfilters alert
■ Use the no version to remove the specified host from the list of recipients.
■ See snmp-server host.
snmp-server trap-source
■ Use to specify the interface whose IP address is used as the source address for
all SNMP traps.
NOTE: When there are multiple IP addresses configured on the IP interface that is
chosen as the SNMP trap source, the SNMP agent automatically uses the primary IP
address of the interface as the SNMP source address on SNMP traps.
■ Example
host1(config)#snmp-server trap-source fastethernet 0/0
172 ■ Configuring Traps
JUNOSe 11.1.x System Basics Configuration Guide
