It consists of a number of related macros for configuring interfaces on CT1 and CE1
modules, as described in Table 54 on page 503.
Some of the macros provide a single configuration function, like configuring the
controller. These are invoked by other macros that are executable from the command
line. A high-level macro invokes several of the executables, acting much like a script
to provide greater functionality.
Table 54: Contents of ds1mac.mac
DescriptionMacro Name
Lists the executable macros in ds1mac.macHelp
Executable macro that configures Cx1 ports; calls macro cntrDs1controllerDs1
Executable macro that configures Frame Relay encapsulation on Cx1 serial
interfaces; calls macro cx1Encap
ds1Encap
Executable macro that configures Frame Relay circuits on Cx1 subinterfaces;
calls macro cx1FRCir
ds1FrCir
Executable macro that configures Cx1 serial Frame Relay interfaces; calls
macros cntrDs1, cx1Encap, and cx1FrCir
configCx1
Configures the Cx1 controller; called by other macroscntrDs1
Configures Frame Relay encapsulation on serial interfaces; called by other
macros
cx1Encap
Configures Frame Relay circuits on the subinterfaces; called by other macroscx1FrCir
The following examples list the complete set of macros contained in ds1mac.mac.
You can run the Help macro to list the other executable macros contained in
ds1mac.mac. To configure Frame Relay on your router with ds1mac.mac, you can
do one of the following:
â– Run the controllerDS1, ds1Encap, and ds1FrCir macros in that order
â– Run the configCx1 macro
In either case, to run the macros you must provide the required values described in
the macros.
<# Help #>
! This file contains the following executable macros:
! controllerDs1
! ds1Encap
! ds1FrCir
! configCx1
<# endtmpl #>
<# controllerDs1 #>
<# if env.argc = 0 #>
! This macro configures your Cx1 controller.
! This macro will configure e1 ports as unframed.
Practical Examples â– 503
Chapter 8: Writing CLI Macros
