Table 28: QoS Schema Objects (continued)
DefinitionObject
Configure QoS schema to export the number of bytes
forwarded from the queue
forwarded-bytes
Configure QoS schema to export the number of forwarded
packets from the queue
forwarded-packets
Configure QoS schema to export the average forwarded
rate within the rate period specified on the statistics profile
of the queue
forwarded-rate
Configure QoS schema to export the number of bytes of
green traffic that were dropped on this queue
green-dropped-bytes
Configure QoS schema to export the number of packets
of green traffic that were dropped on this queue
green-dropped-packets
Configure QoS schema to export the shaping rate enabled
on the parent interface in the scheduling hierarchy
parent-shaping-rate
Configure QoS schema to export the shared shaping rate
enabled on the parent interface in the scheduling
hierarchy
parent-shared-shaping-rate
Configure QoS schema to export the aggregate weight of
the parent interface
parent-weight
Configure QoS schema to export the queue length
attribute
queue-length
Configure QoS schema to export the queue profile namequeue-profile
Configure QoS schema to export the number of bytes of
red traffic that were dropped on the queue
red-dropped-bytes
Configure QoS schema to export the number of red
packets that were dropped on the queue
red-dropped-packets
Configure QoS schema to verify whether the Random
Early Detect (RED) option is enabled on the queue
RED-enabled
Configure QoS schema to export the scheduler profile
name
scheduler-profile
Configure QoS schema to export the shaping mode
enabled on the queue
shaping-mode
Configure QoS schema to export the shaping rate enabled
on the queue
shaping-rate
Configure QoS schema to export the shared shaping mode
enabled on the queue
shared-shaping-mode
Configure QoS schema to export the shared shaping rate
enabled on the queue
shared-shaping-rate
Collecting Bulk Statistics ■ 219
Chapter 4: Configuring SNMP
