Keysight U8903B User Manual

Audio Analyzer Measurement Functions 4
Keysight U8903B User’s Guide 221
Positive peak measurement
Positive peak measurement function mode is a measurement of the greatest positive
voltage level. Positive peak measurement function is applicable for the digital analyzer
only. The positive peak measurement is displayed as shown in Figure 4-43.
Figure 4-43 Digital Analyzer > Functions > Positive Peak menu page
Table 4-18 Digital Analyzer > Functions > Positive Peak menu description
Menu Description
Unit
Press the Unit softkey to select the measurement unit.
– FFS
–dBFS
–%FS
–V
–dBu
–dBV
–dBr
–x
–LSB
–Hex
–Dec
–dBSPL
