Keysight U8903B User Manual

Appendixes A
Keysight U8903B User’s Guide 505
Frequency
Table A-16 Measurement settings > Frequency menu tree description
Tab Level 1 Level 2 Level 3 Description
Frequency
(Signal Generation)
Waveform
–Sine
– Variable Phase
– Square
– Arbitrary
Select the waveform type.
Output Select the output channel.
Waveform Config
Track 1st Ch
Enable
Disable
Enable or disable the tracking of the first channel.
Frequency Set the frequency value.
Amplitude Set the amplitude value.
Waveform Config
DC Offset Set the DC offset value.
Phase->1st Ch
Set the phase value. This setting is only available
when channel 2 is selected.
Frequency
(Signal Analysis)
Sample Size
–2048
–4096
–8192
– 16384
– 32768
– 65536
– 131072
– 262144
– 524288
–1M
–2M
Select the number of samples to be acquired for
the measurement.
Input Range
Auto Range
–On
–Off
Enable or disable the auto input range.
Track 1st Ch
–Enable
– Disable
Enable or disable the tracking of the first channel.
Voltage Range Set the input voltage range.
Frequency
Refer to “Bar chart” on page 548 for the bar
chart menu tree.
