7 Test Sequence Application
378 Keysight U8903B User’s Guide
Table 7-51 DC Level Sweep > Signal Analysis settings menu description
Menu Description
LPF
Press the LPF softkey to select the low-pass filter.
–None
–2 kHz
–3 kHz
–5 kHz
–8 kHz
–10 kHz
–15 kHz
–20 kHz
–22 kHz
–30 kHz
–40 kHz
–50 kHz
–80 kHz
– Custom
HPF
Press the HPF softkey to select the high-pass filter.
–None
–15 Hz
–20 Hz
–22 Hz
–30 Hz
–50 Hz
–70 Hz
–100 Hz
–200 Hz
–300 Hz
–400 Hz
– Custom
Weighting
Press the Weighting softkey to select the weighting filter.
–None
–A
–CCIR 1k
–CCIR 2k
–CCITT
– C-Message
– Custom
Deemphasis
Press the Deemphasis softkey to select the de-emphasis filter.
–None
–50 μs
–75 μs
– Custom
