Appendixes A
Keysight U8903B User’s Guide 463
Functions
(AC Voltage)
Unit
– FFS
–dBFS
–%FS
–V
–dB
–dBV
–dBr
–x
–LSB
–Hex
–Dec
–dBSPL
Select the unit type.
Format
–Off
– Logarithmic
– Linear
Select the reading format of the returned
measurement reading.
Set result as ref. from Channels 1 to 2
Store the measurement result from the selected
channel as the reference frequency.
Ref. Level
Set the reference level value.
There is only one reference level for each channel.
Volt/FS Set the volts/FS reference value.
Detector
–RMS
–Pk-Pk
Select the AC level detection type.
Functions
(DC Voltage)
Unit
– FFS
–V
–Hex
–x
Select the unit type.
Format
–Off
– Linear
Select the reading format of the returned
measurement reading.
Set result as ref. from Channels 1 to 2
Store the measurement result from the selected
channel as the reference frequency.
Ref. Voltage
Set the reference voltage value.
There is only one reference level for each channel.
Table A-8 Digital analyzer menu tree description (continued)
Level 1 Level 2 Level 3 Level 4 Description
