A Appendixes
468 Keysight U8903B User’s Guide
Functions
(Negative peak)
Unit
– FFS
–dBFS
–%FS
–V
–dB
–dBV
–dBr
–x
–LSB
–Hex
–Dec
–dBSPL
Select the measurement unit type.
Format
–Off
– Logarithmic
– Linear
Select the reading format of the returned
measurement reading.
Set result as ref. from Channels 1 to 2
Store the measurement result from the selected
channel as the reference frequency.
Ref. Level
Set the reference level value.
There is only one reference level for each channel.
Volt/FS Set the volts/FS reference value.
Functions
(Phase)
Ref. Channel Set the reference channel number.
Fund Freq
Set the fundamental frequency value.
This setting is only available when the frequency
lock is set to Custom.
Functions
(X-Talk)
Ref. Channel Set the driven channel.
Unit
–dB
– ΔdB
–%
–x
Select the unit type.
Format
–Off
– Linear
–Delta
Select the reading format of the returned
measurement reading.
Set result as ref. from Channels 1 to 2
Store the measurement result from the selected
channel as the reference ratio.
Table A-8 Digital analyzer menu tree description (continued)
Level 1 Level 2 Level 3 Level 4 Description
