Functions
(THD Level)
Odd Harmonic
–ALL
–3
–5
–7
–9
Select the odd harmonics values.
Freq Lock
–Auto
– Gen Lock
– Custom
Select the searching method for the fundamental
frequency.
Fund Freq
Set the fundamental frequency value.
This setting is only available when the frequency lock is
set to Custom.
Functions
(SMPTE IMD)
Unit
–dB
– ΔdB
–%
–x
Select the unit type.
Format
–Off
– Linear
–Delta
Select the reading format of the returned measurement
reading.
Set result as ref.
from
Channels 1 to 2
Store the measurement result from the selected
channel as the reference ratio.
Ref. Ratio
Set the reference ratio value.
There is only one reference ratio for each channel.
Freq Lock
– Gen Lock
– Custom
Select the searching method for the upper and lower
frequencies.
Upper Freq
Set the upper frequency value.
This setting is only available when the frequency lock is
set to Custom.
Lower Freq
Set the lower frequency value.
This setting is only available when the frequency lock is
set to Custom.
Functions
(DFD60268 2nd/
DFD 60268 3rd/
DFD 60118 2nd/
DFD 60118 3rd)
Unit
–dB
– ΔdB
–%
–x
Select the unit type.
Format
–Off
– Linear
–Delta
Select the reading format of the returned measurement
reading.
Set result as ref.
from
Channels 1 to 2
Store the measurement result from the selected
channel as the reference ratio.
Ref. Ratio
Set the reference ratio value.
There is only one reference ratio for each channel.
Table A-9 Bluetooth analyzer menu tree description (continued)
Level 1 Level 2 Level 3 Level 4 Description
To Next Page
