Appendixes A
Keysight U8903B User’s Guide 509
SNR
(Signal Analysis)
Sample Size
–2048
–4096
–8192
– 16384
– 32768
– 65536
– 131072
– 262144
– 524288
–1M
–2M
Select the number of samples to be acquired for
the measurement.
Input Range
Auto Range
–On
–Off
Enable or disable the auto input range.
Track 1st Ch
–Enable
– Disable
Enable or disable the tracking of the first channel.
Voltage Range Set the input voltage range.
SNR
Refer to “Bar chart” on page 548 for the bar
chart menu tree.
Table A-18 Measurement settings > SNR menu tree description (continued)
Tab Level 1 Level 2 Level 3 Description
