Keysight U8903B - Page 538

A Appendixes
538 Keysight U8903B User’s Guide
Receiver Sensitivity
(Signal Analysis)
Fund Freq
Set the fundamental frequency value.
This setting is only available when Freq Lock is set
to Custom.
LPF
–None
–2 kHz
–3 kHz
–5 kHz
–8 kHz
– 10 kHz
– 15 kHz
– 20 kHz
– 22 kHz
– 30 kHz
– 40 kHz
– 50 kHz
– 80 kHz
– Custom
Select the low-pass filter.
HPF
–None
– 15 Hz
– 20 Hz
– 22 Hz
– 30 Hz
– 50 Hz
– 70 Hz
– 100 Hz
– 200 Hz
– 300 Hz
– 400 Hz
– Custom
Select the high-pass filter.
Weighting
–None
–A
– CCIR 1k
– CCIR 2k
– CCITT
– C-Message
– Custom
Select the weighting filter.
Deemphasis
–None
– 50 μs
– 75 μs
– Custom
Select the de-emphasis filter.
Table A-33 Measurement settings > Receiver Sensitivity menu tree description (continued)
Tab Level 1 Level 2 Level 3 Description
