Auto Test | Setting Steps
Icon list
The icons listed below are used to show some of the test condition settings.
 Tests other than LC tests
 LC tests (TOS9303LC only)
: High Pass Filter (Fast) : Volt Measure (RMS) : GND (Low)
: High Pass Filter (Slow) : Volt Measure (Peak) : GND (Guard)
: Low Pass Filter (Fast/ON) : Current RMS (TrueRMS) : Terminals Wire (4Wire)
: Low Pass Filter (Medium) : Current RMS (Average) : Terminals Wire (2Wire)
: Low Pass Filter(Slow) : Root Contact Check (ON) : EC Contact Check (ON)
: Polarity (Normal) : VoltMeter BandWidth (Normal)
: Polarity (Reverse) : VoltMeter BandWidth (Expand)
: 100% OUT (Normal) : Range (Auto)
: 100% OUT (Reverse) : Range (Fix)
