290 User’s Manual TOS93 Series
Specifications | Insulation resistance test section
Measurement function
Item Specifications
Voltmeter Measurement range Negative polarity: 0 Vdc to -1 200 Vdc, positive polarity: 0 Vdc
to 7 500 Vdc
Resolution 0.1 V
Accuracy Negative polarity: ±(1 % of reading + 1 V), positive polarity:
±(1.
2 % of reading + 1 V)
Resistance
meter
Measurement range 0.001 MΩ to 100.0 GΩ (in the range of maximum rated
current of 1 mA to 5 nA)
Accuracy
1 2
(when GND is set
to Guard)
(i: measured
current)
(R: measurement
resistance)
5 nA ≤ i ≤ 50 nA
3
500.000 MΩ ≤ R < 1.000 GΩ: ±(15 % of reading + 0.5 MΩ)
1.000 GΩ ≤ R < 10.000 GΩ: ±(15 %
of reading + 5 MΩ)
10.000 GΩ ≤ R ≤ 100.000 GΩ: ±(20 %
of reading + 200 MΩ)
50 nA < i ≤ 100 nA
*3
200.000 MΩ ≤ R < 1.000 GΩ: ±(10 % of reading + 0.5 MΩ)
1.000 GΩ ≤ R < 10.000 GΩ: ±(10 %
of reading + 5 MΩ)
10.000 GΩ ≤ R < 50.000 GΩ: ±(10 %
of reading + 50 MΩ)
50.000 GΩ ≤ R ≤ 100.000 GΩ: ±(20 %
of reading + 200 MΩ)
100 nA < i ≤ 200 nA
4
100.000 MΩ ≤ R < 1.000 GΩ: ±(7 % of reading + 0.5 MΩ)
1.000 GΩ ≤ R < 2.000 GΩ: ±(7 % of reading + 5
MΩ)
2.000 GΩ ≤ R < 10.000 GΩ: ±(7 % of reading + 10
MΩ)
10.000 GΩ ≤ R < 50.000 GΩ: ±(7 % of reading + 100
MΩ)
200 nA < i ≤ 1 µA
*4
10.000 MΩ ≤ R < 100.000 MΩ: ±(5 % of reading + 0.05 MΩ)
100.000 MΩ ≤ R < 1.000 GΩ: ±(5 % of reading + 0.5
MΩ)
1.000 GΩ ≤ R < 10.000 GΩ: ±(5 % of reading + 5
MΩ)
10.000 GΩ ≤ R < 25.000 GΩ: ±(5 % of reading + 50
MΩ)
1 µA < i ≤ 1 mA
*4
0.001 MΩ ≤ R < 10.000 MΩ: ±(2 % of reading + 0.003 MΩ)
10.000 MΩ ≤ R < 100.000 MΩ: ±(2 % of reading + 0.03
MΩ)
100.000 MΩ ≤ R < 1.000 GΩ: ±(2 % of reading + 0.3
MΩ)
1.000 GΩ ≤ R < 5.000 GΩ: ±(2 % of reading + 3
MΩ)
Accuracy
5
(when GND is set
to Low)
(i: measured
current)
(R: measurement
resistance)
5
nA ≤ i ≤ 50 nA
*3
500.000 MΩ ≤ R < 1.000 GΩ: ±(25 % of reading + 0.5 MΩ)
1.000 GΩ ≤ R < 10.000 GΩ: ±(25 %
of reading + 5 MΩ)
10.000 GΩ ≤ R ≤ 100.000 GΩ: ±(30 %
of reading + 200 MΩ)
50 nA < i ≤ 100 nA
*3
200.000 MΩ ≤ R < 1.000 GΩ: ±(20 % of reading + 0.5 MΩ)
1.000 GΩ ≤ R < 10.000 GΩ: ±(20 %
of reading + 5 MΩ)
10.000 GΩ ≤ R < 50.000 GΩ: ±(20 %
of reading + 50 MΩ)
50.000 GΩ ≤ R ≤ 100.000 GΩ: ±(30 %
of reading + 200 MΩ)
100 nA < i ≤ 200 nA
*4
100.000 MΩ ≤ R < 1.000 GΩ: ±(10 %
of reading + 0.5 MΩ)
1.000 GΩ ≤ R < 2.000 GΩ: ±(10 %
of reading + 5 MΩ)
2.000 GΩ ≤ R < 10.000 GΩ: ±(10 %
of reading + 10 MΩ)
10.000 GΩ ≤ R < 50.000 GΩ: ±(10 %
of reading + 100 MΩ)
200 nA < i ≤ 1 µA
*4
10.000 MΩ ≤ R < 100.000 MΩ: ±(5 % of reading + 0.05 MΩ)
100.000 MΩ ≤ R < 1.000 GΩ: ±(5 % of reading + 0.5
MΩ)
1.000 GΩ ≤ R < 10.000 GΩ: ±(5 % of reading + 5
MΩ)
10.000 GΩ ≤ R < 25.000 GΩ: ±(5 % of reading + 50
MΩ)
1 µA < i ≤ 1 mA
*4
0.001 MΩ ≤ R < 10.000 MΩ: ±(2 % of reading + 0.003 MΩ)
10.000 MΩ ≤ R < 100.000 MΩ: ±(2 % of reading + 0.03
MΩ)
100.000 MΩ ≤ R < 1.000 GΩ: ±(2 % of reading + 0.3
MΩ)
1.000 GΩ ≤ R < 5.000 GΩ: ±(2 % of reading + 3
MΩ)
Hold function The resistance measurement after a test is finished is held
while the pass judgment is displayed.
Offset cancel function Cancels up to 2 000 GΩ of the unnecessary insulation
resistance across output cables and the like. OFF function
available.
1 Humidity: 70 %rh or less (no condensation), when there is no interference caused by wobbly test leads or other
problems.
