LED indicator:
Under normal circumstances, the LED of the door contact will be off. It only flashes in the
following cases:
If the door contact is removed or turned in a different position (the tampering
contact is opened).
If the battery is low and the sensor is opened.
In the test mode (e.g. range test) – for three minutes after the learn button was
pressed.
Battery:
The door contact requires a 3V ½AA (CR2) lithium battery. The average battery life is 2.6
years. When the sensor transmits a low battery warning, the battery will last for approx.
one month.
Connecting the door contact and putting it into operation
1. Remove the battery breaker from the back of the contact to energise the door contact.
2. Open the main menu of the alarm panel.
3. Open the menu “Sensors” “Add”.
4. Click “Start”.
5. Press the learn button of the door contact. The LED of the door contact will flash.
6. The alarm panel will confirm the successful addition with a brief signal tone and
display the sensor in the menu “Sensors” ”Add”. Click on next to the listed sensor
to finish the connection process.
Range test:
4. Open the alarm panel menu “Sensors” “Range” and press “Start”.
5. Press the learn button.
6. The sensor and the signal strength are indicated. The higher the indicated number
the better the reception (1-9).
Please note:
If the signal strength at the place of installation is below 4, we advise to use a wireless
repeater, since it is normal that the signal strength may fluctuate for 2-3 points, thus,
a signal loss is possible.
