Dual-way motion detector
Product description:
The dual-way motion detector prevents false alarms due to a double motion detection
method – PIR and microwave detection. An alarm is only triggered if both methods detect
a motion.
The PIR/microwave motion detector consists of a front and a back. The mainboard to
make various settings/adjustments is located on the front. You can mount the back either
to flat surfaces or in corners by means of one of the two provided mounts. Open the
sensor by pressing a tool (e.g. a screwdriver) into the plastic notch at the bottom.
Sensor data:
Dimensions (without mount) 6.33 x 11.25 x 6.2 cm (2.49 x 4.29 x 2.44 inches)
Weight: 141 grams (0.31 lbs.)
Place of installation: Only indoors
Operating temperatures: -10 °C to 45 °C (14F to 113F)
Humidity: Maximum 95 % (non-condensing)
Microwave frequency: 10.525 GHz
Radio frequency: 868.6375 MHz
1. IR motion detection LED (green)
In test mode, the LED lights up with every motion detected by the IR sensor.
2. Microwave detection LED (blue)
In test mode, thee LED lights up with every motion detected by the microwave
sensor.
3. Transmitter LED (red)
The LED flashed upon every transmission in test mode, in case of a low battery,
and if the tampering contact is open.
4. Sensor
5. Tamper contact
6. JP 1
Jumper 1 is reserved.
7. Activate/deactivate supervisor jumper switch 2 (JP2)
