1. LED / Learn button
2. Magnetic contact markings
3. Switch for the status monitoring
4. Tampering contact
5. Battery compartment
6. Mounting hook
7. Mounting holes
8. Notch for opening the sensor
9. Tampering contact opening
10. Opening for the battery breaker
11. Mounting holes of the magnet mount
12. Mount for the magnet top
13. Magnet (needs to be placed at the magnetic contact marking [2])
LED indicator:
Under normal circumstances, the LED of the door contact V2 is off. It only flashes in the
following cases:
If the door contact V2 is removed or turned in a different position (tampering
contact is triggered).
If the battery is low and the sensor is opened.
In the test mode (e.g. range test) during the first three minutes after pressing the
learn button.
Battery:
The door contact V2 requires a 3V ½AA (CR2) lithium battery. The average battery life is
5 years (approx. 10 uses a day). When the sensor transmits the low battery signal to the
alarm panel, the battery has enough power for approx. four more weeks.
Connecting the door contact V2 and putting it into operation
1. Remove the battery breaker from the back of the contact to energise the door
contact V2.
2. Open the main menu of the alarm panel.
3. Open the menu “Sensors” “Add”.
4. Click “Start”.
5. Press the learn button of the door contact V2. The LED of the door contact V2 will
flash.
6. The alarm panel will confirm the successful addition with a brief signal tone and
display the sensor in the menu “Sensors” ”Add”. Click on next to the listed
sensor to finish the connection process.
Range test:
1. Open the alarm panel menu “Sensors” “Range” and press “Start”.
2. Press the learn button.
3. The sensor and the signal strength should be indicated. The higher the indicated
number the better the reception (1-9).
