Door contact V2
Product description:
The LUPUS door contact V2 is an integral part of your alarm system and is used to secure
your windows and doors. The contact consists of two parts: one is fixed at your window
or door frame, the other one is fixed at the wing of the door or window sash. Thus, the
window/ door contact V2 immediately registers if a window or door is opened or closed.
The door contact V2 is available in three colors: white, brown, and anthracite.
Sensor data:
Dimensions sensor 86.9 x 27.7 x 21.2mm (3.42 x 1.09 x 0.83 inches) (LxWxH)
Dimensions magnet 46 x 12,2 x 10,3 mm (1.8 x 0.48 x 0.4 inches) (LxWxH)
Weight Sensor: 34g (0.07 pounds), Magnet: 10g (0.02 pounds)
Place of installation Only indoors (windows/ doors)
Working environment -10°C to 50°C (14F to 122F)
Humidity Maximal 85% (non-condensing)
Radio frequency 868.35 MHz
Detection method Magnetic measurement
Sensor (top) Sensor (bottom)
Magnet (bottom) Magnet (top) Magnet (side)
