Sensor input
Product description:
The sensor input is a device with two potential-free switch contacts. The sensor input is
connected wirelessly to the alarm panel. If the contacts are closed, an alarm is triggered.
Therefore, it can be used for already available window/ door contacts in a wired system
or additional sensors by third-party providers (access control, fingerprint, light barrier,
door bolt contact etc.).
1. LED indicator and Learn button
2. Mounting holes
3. Tampering contact
4. Battery breaker
5. Screw to open housing
6. Potential-free switch contact (CON4)
7. Reserved (CON5) – no function
8. DIP switches for precision adjustment
LED indicator:
The LED lights up with every signal transmission and if the tampering contact is triggered.
Battery:
The sensor input requires a ½ AA 3.6 V Lithium battery. The average battery life is 2.8
years. The alarm panel is informed if the battery is running low.
