ZigBee status:
Flashes red once:
Status display is reset.
Flashes red twice:
The status display was successfully added to the alarm panel
Flashes every twenty minutes:
The status display has lost contact to the alarm panel.
2. Casing screw
3. Casing hook
4. Battery compartment
The status display uses a CR123A 3V lithium battery. The approximate battery
live is two years.
If the battery runs low, you will receive a warning by the alarm panel in due
time.
5. Learn-button
Press this button for ten seconds to reset the status display and to send a
new connection request to the alarm panel.
Connecting the status display and putting it into operation
1. Insert the batteries into the battery compartment of the status display.
2. You can only add the status display to the alarm panel within the first three
minutes after the battery has been inserted.
3. Open the web interface of the alarm panel and go to the menu “Sensors”
“Add” and press “Start”.
4. Press and hold the learn-button (5) for approx. ten seconds. The LED (1) will
flash briefly.
5. When the status display is recognised by the alarm panel, the LED will flash
twice.
6. As soon as the connection request of the status display is received by the alarm
panel, the status display is listed in the sensor list. Click on to add the status
display to the alarm panel.
Range test:
1. Open the alarm panel menu “Sensors” “Range” and press “Start”.
2. Press the learn button.
3. The sensor and the signal strength should be indicated. The higher the indicated
number the better the reception (1-9).
Please note:
If the signal strength at the place of installation is below 4, we advise to use a ZigBee
repeater, since it is normal that the signal strength may fluctuate for 2-3 points, thus,
a signal loss is possible.
