Lupus Electronics XT 1 Plus - Shutter Relay V2 Installation

278
Shutter relay V2
CAUTION:
Only certified electricians or persons instructed in electrical engineering with
knowledge and understanding of electric current and the inherent risks are
allowed to execute the installation.
Attention:
 This product is not compatible with the “XT1” or the XT2 without an additional
“upgrade dongle to XT2 Plus!”
Product description:
The shutter relay V2 allows you to control your shutters, awnings, or blinds via your
smartphone, tablet, or computer. Additionally, you can set-up automations that will open
or close your shutters when you enter or leave your home, dependent on time,
brightness, temperature, or humidity. Of course, you can continue to use your regular
push buttons.
Technical data
Dimensions
Approx. 51 x 49 x 22 mm (2. x 1.92 x
0.86 inches) (W x H x D)
Weight
Approx. 50g (0.11 lbs)
Detection method
-
Sensor type
-
Tampering protection
No
Status displayed
Yes, red LED in front
Status checked and displayed in the alarm
panel
Yes
Radio frequency
2.4 GHz ZigBee S
Radio performance
Max. 10 mW
Transmission range
Approx. 30 to 100 meters (32 to 109
yards) (depending on the local
conditions)
Power supply
230 V / 50 Hz
Operating temperature and max. humidity
-10°C to 45°C (14F to 113F), max. 85 %
(not condensing)
CAUTION:
Do not open the chassis! You risk a fatal electric shock! Disconnect the power
supply / circuit / the fuse before performing changes on the wiring!
