Status display
Please note:
This product is not compatible with the XT1 or XT2 without “Upgrade dongle to XT2
Plus.”
Description:
The status display shows you if your alarm panel is armed or disarmed.
Sensor-data:
Place of installation: Indoor and outdoor
Protection class: IPX4
Working environment: -10°C to +45°C (14F to 113F)
Humidity: Maximal 85% (non-condensing)
Radio frequency: 2.4 GHz
Batteries: CR123A 3V lithium battery
Dimensions: 74 x 46 x 22mm (2.91 x 1.81 x 0.86 inches)
1. LED-display
System status:
Off: alarm panel is disarmed
Flashes green once every four seconds: The alarm panel is armed.
Flashed green twice every four seconds: The alarm panel is in home mode (1-
3).
Flashes red once every three seconds: Alarm notification. Will be disabled
upon disarming the alarm panel.
Please note:
If an alarm is triggered (also a silent one), the status display always lights up
red.
