DIP switch functions:
Use the switches 1-4 to assign a function to the sensor input and, thus, define whether it
is listed in the alarm panel as door contact, motion detector, smoke detector, or panic
button. Never activate (ON) more than one of the four switches simultaneously.
Afterwards, add the sensor to the alarm panel.
Connecting the sensor input and putting it into operation:
To put the wireless sensor input into operation, proceed as follows:
1. Insert the supplied batteries.
2. Define the function with the switch SW 1-4.
3. Connect the contact to the sensor input’s potential-free switch contact (6 - CON4).
4. Set SW5 to ON in order to activate the status signal transmission. If you do not
activate SW5, you the supervision function of the alarm panel will inform you about
a supervision error.
5. Close the housing.
6. Open the configuration page of the alarm panel, open the menu “Sensors”
“Add”, and press “Start”.
7. Press the Learn button of the wireless sensor input for about one second.
8. The configuration page of the alarm panel should list the sensor input.
9. Add the sensor input via .
Range test:
1. Open the alarm panel menu “Sensors” “Range” and press “Start.”
2. Press the learn button.
SW1
Door contact (DC-11C2)
ON
Activated (default)
OFF
Deactivated
SW2
Motion detector
ON
Activated
OFF
Deactivated (default)
SW3
Smoke detector
ON
Activated
OFF
Deactivated (default)
SW4
Panic button
ON
Activated
OFF
Deactivated (default)
SW5
Status signal
ON
Activated
OFF
Deactivated
SW6
CON4 NO/NC
ON
Normally open (NO)
OFF
Normally closed (NC default)
SW7
Reserved
SW8
Reserved
