Connecting the 360° PIR motion detector and putting it into operation
1. Insert the included battery into the battery compartment of the 360° PIR motion
detector.
2. The 360° PIR motion detector will now enter a boot process. This takes approx.
30 seconds and the LED will flash during this time. Please do not trigger the
motion detection during this period – every detected motion during the boot
process will result in an extension of the required time.
3. Open the web interface of the alarm panel and go to the menu “Sensors”
“Add” and press “Start”.
4. Press the learn button of the 360° PIR motion detector.
5. The alarm panel will confirm the successful addition with a brief signal tone
and display the 360° PIR motion detector in the menu “Sensors” ”Add”. Click
on next to the listed sensor to finish the connection process.
Range test:
1. Open the alarm panel menu “Sensors” “Range” and press “Start”.
2. Press the learn button.
3. The sensor and the signal strength should be indicated. The higher the indicated
number the better the reception (1-9).
Please note:
If the signal strength at the place of installation is below 4, we advice to use
wireless repeater, since it is normal that the signal strength may fluctuate for 2-3
points, thus, a signal loss is possible
Place of installation:
The 360° PIR motion detector designed to be mounted on the ceiling.
At a height of 2.7 meters (8.85 feet), the detection range is approx. 6 meters (19.68
feet).
At t height of 4 meters (13.12 feet), the detection range is approx. 8 meters (26.24
feet).
The 360° PIR motion detector should be installed at a location that a burglar has
to enter the detection range when moving through a room.
The best results are achieved if a person moves from one side of a room to the
other side. Install the sensor accordingly.
